Overview
MiTR Staff Bus is a modern bus powered by the advanced and proven ZD 30 engine – ensuring best of both worlds enhanced with i-Gen6 BS6 technology; Power and Fuel Efficiency. It takes comfort to a whole new level with its ergonomically designed interiors. Its well planned safety features. Designed keeping Indian roads and driving conditions in mind, makes it extremely safe. MiTR makes every ride comfortable, safe and quick, adding business value to operators at the same time.
Safety
In compliance with the latest Bus Body Code (AIS 052 and AIS 153)), MiTR is equipped with safety features that ensure safety of passsengers alongwith Vehicle tracking sysytem. It is 100% rollover compliant and has a sturdy body cage design with structural reinforcements that ensure superior safety. MiTR offers superior drive comfort for its passengers with its superior stability due to a low centre of gravity. Safety is enhanced with a guarded driver saloon, two emergency exit doors (optional) and brake boosters. Additional safety features include strategically positioned grab rails, tooth guard, individual seat belts, a fire extinguisher, an optional GPS connectivity and first-aid kits
Performance and Fuel Efficiency
The MiTR is thoughtfully engineered to ensure minimal maintenance and better profitability for operators. With an advanced and powerful ZD30 engine with highly efficient 2.2 Bosch Cri Common Rail System with advance direct injection complying to 10% more mileage, the MiTR offers matchless performance and fuel efficiency. A flat torque over a wide engine RPM band ensures lesser gear shifts, leading to improved fuel saving even during frequent start and stop. Adjustable steering and shorter turning radius of the MiTR reduces driving stress. . Also to add to your benefits now a warranty term of 3 Years/3Lakh kms is offered to you.
Features
Zyaada TECHNOLOGY
- ADVANCED Selective Catalytic Reduction (SCR) Technology - Better Reduction of NOx, CO, HC & PM
- GREENER AND CLEANER TECHNOLOGY
Zyaada MILEAGE
- Get MORE Mileage with Superior and Proven ZD30 Engine
- Highly efficient Bosch 2.2 CRi Common Rail System with Advanced Direct Injection
- 10% MORE MILEAGE
Zyaada POWER
- Best in Class Power & Torque
- Advanced Gear Box with Dual Synchro Cones
- Bigger Clutch 310 mm
- First in Class Cable Gear Shift Mechanism
- First in Class Parabolic Suspension
- Braking with LCRV
- POWER: 140 HP | TORQUE: 360 Nm
Zyaada SAFETY
- AIS 153 & AIS 052 Bus Body Code Certified
- Vehicle Tracking System (VTS)
- Fire Detection and Alarm System (FDAS)
- SUPERIOR SAFETY
Zyaada COMFORT
- Designed for Indian Roads
- Ergonomically Designed Passenger Seats
- Ergonomically Designed Driver Cabin
- Tiltable Power Steering for Fatigue Free Driving
- FACTORY-FITTED AC AND POWER STEERING
Zyaada BHAROSA
- Engine & Transmission warranty of 3 years/ 3 Lakh km which ensures customers can be Tension Free
- High Reliability and Proven Performance
- 3 YEARS OR 3 LAKH km
| MiTR - 3700 MM WB (7m WB) | MiTR - 4270 MM WB (8m WB) | ||||
| Seating | |||||
| Seating Capacity | 19+D (Push back) 23+D High Back Seats 27+D – Standard Seats 25+D – Double Door – Standard Seats |
27+D - High Back Seats 22+D (Push Back) 31+D Single Door – Standard Seats 29+D – Double Door – Standard Seats |
|||
| Powertrain | |||||
| Engine Type | ZD30 DDTi CRD Engine BS VI | ||||
| Cubic Capacity | 2953 cc | ||||
| Maximum Power output (Hp) @ rpm | 140 HP @ 2750 rpm | ||||
| Maximum Torque (Nm) | 360 NM @ 1350-2750 rpm | ||||
| Clutch | 310 mm diameter Single dry plate, Diaphragm- Push type, Hydraulic actuated | ||||
| Transmission | Fully Synchronised 5 Speed Manual Gearbox | ||||
| Fuel System | |||||
| Fuel Tank Capacity (Litre) | 90 | ||||
| Brakes | |||||
| Service Brakes | Vacuum assisted Hydraulic brake | ||||
| Parking Brakes | Transmission mounted - 220 x 45 Drum | ||||
| Suspension and Tyres | |||||
| Front & Rear Suspension | Parabolic, Overslung suspension with Double acting ShockAbsorbers | ||||
| No. of Tyres | Front 2, Rear 4, Spare - 1 | ||||
| Tyre Size | 7.00 x 16, 14 PR | 7.50 x 16, 16 PR | |||
| Weight | |||||
| Gross Vehicle Weight (kg) | 6650 | 7200 | |||
| Dimensions | |||||
| Wheel Base (mm) | 3700 | 4270 | |||
| Overall Dimension (mm) Wide Body (L x W x H) |
7060 X 2200 X 2630 (Non AC), 7060 x 2200 X 2850 (AC) |
7970 X 2200 X 2630 (Non AC), 7970 X 2200 X 2850 (AC) |
|||
| Passenger Platform Height (mm) | 790 | 815 | |||
| Min. Turning Radius (m) | 7.2 | 8.3 | |||
| AC Specifications | |||||
| Compressor | 220 cc, 20 Kw | 220 cc + 160 cc, 25 Kw | |||
| Cooling Unit | Roof Mounted | Roof Mounted | |||
| Window Glass | Tinted (30%) | Tinted (30%) | |||
| Electricals | |||||
| Electrical Description | Single Pole 12 V | ||||
| Battery (in Ah) (Non AC/ AC) | 75/110 | ||||
| Alternator (A) (Non AC/ AC) | 90/140 | ||||
| Features | MiTR 3700 WB (7m) | MiTR 4270 WB (8m) | ||||
|---|---|---|---|---|---|---|
| Comfort & Convenience | ||||||
| Tiltable Power Steering | ||||||
| Reclining & Sliding Driver Seat | ||||||
| Grab Rail on the Passenger Door | ||||||
| Modern Dual-tone Dashboard | ||||||
| Dual Tone Vinyl Seats | ||||||
| Interiors | ||||||
| Digital Odometer | ||||||
| Trip Odometer | ||||||
| Flooring - Vinyl Button Type | ||||||
| Roof Panel - Pre-painted GI Sheet | ||||||
| Lockable Glove Box | ||||||
| Safety | ||||||
| Low Vacuum in Brake Booster Indicator | ||||||
| Steering Lock with Single Key for Door and Fuel Tank Lid | ||||||
| Safety Light in Door Footwell Area | ||||||
| Passenger Door - Jack & Knife (Opens inwards) | ||||||
| Fire Extinguisher | ||||||
| Partition behind Driver Seat | ||||||
